Technical Details:
| Camera | |||||||||
| Image Sensor | 1/2.8" STARVIS™ CMOS | ||||||||
| Pixel | 2MP | ||||||||
| Max. Resolution | 1920 (H) x 1080 (V) | ||||||||
| ROM | 16 MB | ||||||||
| RAM | 256 MB | ||||||||
| Electronic Shutter Speed | 1/3 s–1/100000 s | ||||||||
| Scanning System | Progressive | ||||||||
| Min. Illumination |
|
||||||||
| Illumination Distance | 100 m (328.08 ft) | ||||||||
| Illuminator On/Off Control | Auto/Manual | ||||||||
| Illuminator Number | 6 | ||||||||
| Lens | |||||||||
| Focal Length | 4.8 mm–120 mm | ||||||||
| Optical Zoom | 25x | ||||||||
| Focus Control | Auto/Semi-Auto/Manual | ||||||||
| Max. Aperture | F1.6–F3.5 | ||||||||
| Field of View |
|
||||||||
| Close Focus Distance | 0.1 m–1.5 m (0.33 ft–4.92 ft) | ||||||||
| Iris Control | Auto/Manual | ||||||||
| DORI Distance |
|
||||||||
| PTZ | |||||||||
| Pan/Tilt Range | Pan: 0°–360°Tilt: -15°–+90°; auto flip 180° | ||||||||
| Manual Control Speed | Pan: 0.1°–200°/s; Tilt: 0.1°–120°/s | ||||||||
| Preset Speed | Pan: 240°/s; Tilt: 200°/s | ||||||||
| Presets | 300 | ||||||||
| Tour | 8 (up to 32 presets per tour) | ||||||||
| Pattern | 5 | ||||||||
| Scan | 5 | ||||||||
| Speed Adjustment | Support | ||||||||
| Power-off Memory | Support | ||||||||
| Idle Motion | Preset/Tour/Pattern/Scanning | ||||||||
| Protocol | DH-SD Pelco-P/D (auto recognition) |
||||||||
| Video | |||||||||
| Frame Rate | 1080P (25/30 fps), 720P (25/30/50/60 fps) | ||||||||
| Resolution | 1080P (1920 × 1080); 720P (1280 × 720); D1 (704 × 576/704 × 480) |
||||||||
| Day/Night | Support | ||||||||
| BLC | Support | ||||||||
| WDR | 120 dB | ||||||||
| HLC | Support | ||||||||
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp | ||||||||
| Gain Control | Auto/Manual | ||||||||
| Noise Reduction | 2D / 3D | ||||||||
| Defog | Electronic | ||||||||
| Digital Zoom | 16x | ||||||||
| Flip | 0°/180° | ||||||||
| Privacy Masking | Up to 24 areas | ||||||||
| CVI Product Output Mode | CVI; TVI; AHD; CVBS | ||||||||
| Audio | |||||||||
| Compression | G.711a; G.711Mu | ||||||||
| Certifications | |||||||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL60950-1+CAN/CSA C22.2, No.60950-1 |
||||||||
| Port | |||||||||
| Audio Input | 1 (LINE IN; bare wire) | ||||||||
| Alarm Input | 2 | ||||||||
| Alarm Output | 1 | ||||||||
| Power | |||||||||
| Power Supply | DC 12V/3A ± 10% | ||||||||
| Power Consumption | 9.6 W 23.2 W (IR light on, PTZ) |
||||||||
| Environment | |||||||||
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) | ||||||||
| Operating Humidity | ≤ 95%RH | ||||||||
| Protection | IP66; TVS 6000V lightning protection; surge protection | ||||||||
| Structure | |||||||||
| Dimensions | 295.4 mm × Φ160.0 mm (11.63" × Φ6.30") | ||||||||
| Net Weight | 3 kg (6.61 lb) | ||||||||
| Gross Weight | 4.2 kg (9.26 lb) | ||||||||
