Technical Details:

• Compatibility: PTZ dome cameras, DVRs, network video servers
• Keys: Electromechanical

• Temperature:	Mono LCD
  	128 x 64 resolution
  	Size: 3 x 1.3" (75.2 x 33.85 mm)

• Joystick: 3-axis, vector-solving, twisting function and return to center
• Keyboard Connectors: RJ45, RS-232, RS-485, RS-422, USB

• Direct Interface (DI)	RS-232/RS-485
  	DVR Protocol: DH2
  	PTZ Protocol: DH-SD/Pelco D, P, D1, P1

• Network: RJ45 Ethernet

• Power Supply:	Input: 100-240 VAC, 50/60 Hz
  	Output: 12 VDC, 1000 mA

• Power Consumption: 5 W
• Operating Temperature: 14 to 131°F (-10 to 55°C)
• Operating Humidity: 10 to 90%
• Atmospheric Pressure: 86 to 106 kpa

• Dimensions:	Without Joystick: 13 x 6.3 x 1.5" (33 x 16 x 3.75 cm)
  	With Joystick: 13 x 6.3 x 3.9" (33 x 16 x 10 cm) Weight: 5.5 lb (2.5 kg)
