Technical Details:
Camera | ||||||||||||||||
Image Sensor | 1/2.7 inch CMOS | |||||||||||||||
Max. Resolution | 2592 (H) × 1944 (V), 5MP | |||||||||||||||
Scanning System | Progressive | |||||||||||||||
Electronic Shutter Speed |
|
|||||||||||||||
S/N Ratio | >65dB | |||||||||||||||
Min. Illumination | 0.02Lux/F2.0(Color), 30IRE, 0Lux IR on | |||||||||||||||
Illumination Distance | Up to 20m (66feet) | |||||||||||||||
Illuminator On/Off Control | Auto; manual | |||||||||||||||
IR LED Number | 1 | |||||||||||||||
Pan/Tilt/Rotation Range |
|
|||||||||||||||
Lens | ||||||||||||||||
Lens Type | Fixed lens/ Fixed iris | |||||||||||||||
Mount Type | Board-in | |||||||||||||||
Focal Length | 2.8mm (3.6mm Optional) | |||||||||||||||
Max. Aperture | F2.0 | |||||||||||||||
Angle of View |
|
|||||||||||||||
Focus Control | N/A | |||||||||||||||
Close Focus Distance | 800mm(1400mm) 31''(55'') |
|||||||||||||||
DORI Distance |
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively
|
|||||||||||||||
Video | ||||||||||||||||
Frame Rate | 20fps@5MP, 25/30fps@4MP, 25/30fps@1080P | |||||||||||||||
Resolution | 5MP (2592×1944) | |||||||||||||||
Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||||||||||||
Day/Night | Auto (ICR) / Manual | |||||||||||||||
OSD Menu | Multi-language | |||||||||||||||
BLC | BLC/HLC/WDR | |||||||||||||||
WDR | DWDR | |||||||||||||||
White Balance | Auto; manual | |||||||||||||||
Gain Control | AGC | |||||||||||||||
Noise Reduction | 2D NR | |||||||||||||||
Smart IR | Auto; manual | |||||||||||||||
PIR | ||||||||||||||||
Detection | Passive infrared | |||||||||||||||
Detection Range | 10m, 110° | |||||||||||||||
Alarm Prompt | White light | |||||||||||||||
White Light Mode | Alert / Lighting | |||||||||||||||
Installation height | Default bracket, wall mount, 2.2-3m | |||||||||||||||
Certifications | ||||||||||||||||
Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|||||||||||||||
Interface | ||||||||||||||||
Audio Interface | N/A | |||||||||||||||
Eelectrical | ||||||||||||||||
Power Supply | 12V ±30% DC | |||||||||||||||
Power Consumption | Max 5W (12V DC, white light on) | |||||||||||||||
Environment | ||||||||||||||||
Operating Temperature | 10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH * Start up should be done at above -10°C (14°F) |
|||||||||||||||
Storage Temperature | -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH | |||||||||||||||
Protection Grade | IP67 | |||||||||||||||
Structure | ||||||||||||||||
Casing | Aluminium (Inner Core) + Plastic (Cover) | |||||||||||||||
Camera Dimensions | Φ110mm×96.1mm(Φ4.33"×3.78") | |||||||||||||||
Net Weight | 0.28kg (0.61lb) | |||||||||||||||
Gross Weight | 0.35kg (0.77lb) |
