Technical Details:
| Basic | |
| Illuminator Number | 6 IR illuminators, brightness adjustable |
| Image Sensor | 1/2.8'' CMOS |
| Image Resolution | 1920 × 1080 (OSD black strip excluded) |
| Video Resolution | Main stream: 1080P (1920 × 1080)/720P (1280 × 720) Sub stream: 720P (1280 × 720)/D1 (704 × 576, 704 × 480)/CIF (352 × 288, 352 × 240) |
| Video Frame Rate | PAL: Main stream (1920 × 1080@25fps, 1280 × 720@25fps), sub stream (1280 × 720@25fps, 704 × 576@25fps, 352 × 288@25fps) NTSC: Main stream (1920 × 1080@30fps, 1280 × 720@30fps), sub stream (1280 × 720@30fps, 704 × 408@30fps, 352 × 240@30fps) |
| Bit Rate | H.264B: 32Kbps–32768Kbps H.264M: 32Kbps–32768Kbps H.264H: 32Kbps–32768Kbps H.265: 32Kbps–32768Kbps MJPEG: 512Kbps–65536Kbps |
| Video Compression | H.264B/H.264M/H.264H/H.265/MJPEG |
| Picture Encoding Format | JPEG |
| Noise Reduction | 3DNR |
| White Balance | Full auto, auto color temperature range, customized color temperature |
| Electronic Shutter Speed | 1/50–1/10000, auto or manual |
| WDR | 96 db |
| Edge Enhancement | Yes |
| Exposure Mode | Full auto, customized auto, customized |
| Iris Control | Auto iris (W: 1.6–T: 3.3) |
| Performance | |
| Trigger Mode | Video detection; I/O coil; video detection and I/O coil |
| Shutter | Single shutter |
| Storage | 1 built-in TF card port. Supports Kingston 16G, 32G, 64G, and 128G; Dahua 16G, 32G, 64G, and 128G; SanDisk 16G, 32G, 64G, and 128G |
| Image Tampering Prevention | Yes. Video/picture can be checked through watermark and verification |
| Field of View | Horizontal: 108.1° (W)–30.3° (T); Vertical: 56.3° (W)–17.1° (T); Diagonal: 130.9° (W)–34.8° (T) |
| Illumination Distance | 12 m (39.37 ft) |
| Capture Range | 3 m–6 m (9.84 ft–19.69 ft) |
| Detected Lane Width | 3 m –4 m (9.84 ft–13.12 ft) |
| Min Ambient Illuminance | 0.002 Lux. Illuminator is designed with the camera for illumination |
| Max Speed that the Camera Detects | 30 km/h |
| Alarm Event | Alarm in the case of no storage card, not enough storage space, storage card error, network disconnection, IP conflict, and illegal access |
| Security | Authorized username and password, MAC address binding, HTTPS encryption, IEEE 802.1x, and network access control |
| OSD Overlay | Supports overlay of time, address (position of channel), lane (number/direction), plate (number and color), vehicle (speed, color, type) |
| Automatic Network Replenishment (ANR) | Yes. Platform/FTP |
| Auto Registration | Yes |
| Intelligence | |
| Vehicle Detection | Vehicle capture rate ≥99% |
| Vehicle Recognition | Supports recognizing vehicle type, vehicle logo, vehicle series, vehicle color, license plate, features of driver and front-seat passenger, and vehicle without plate. Vehicle recognition rate ≥95% |
| Video Metadata | Yes |
| Intelligent Track Frame | Intelligent frame display. Supports displaying vehicle plate and vehicle path |
| Port | |
| Lens Mount | Φ14 |
| Analog Output | 1 |
| Network | 1 100/1000M Ethernet port (RJ-45) |
| RS-485 | 2 |
| RS-232 | 1 |
| Alarm Input | 3, optocoupler input (on-off input) |
| Alarm Output | 3 ports. 2-channel optocoupler output, 1-channel relay output, which can connect to devices such as barriers |
| Audio Input | 1-channel RCA port |
| Audio Output | 1-channel RCA port |
| General | |
| Power Supply | 12V DC, 24V AC, PoE+ |
| Power Consumption | ＜20W |
| Operating Temperature | −30°C to +65°C (−22°F to +149 °F) |
| Operating Humidity | 10%RH–90%RH (no condensation) |
| Casing | Metal and plastic |
| Protection Grade | IP67 |
| Dimensions | 486.7 mm × 124.3 mm × 185.5 mm (19.16'' × 4.89'' × 7.30'') (L × W × H) |
| Net Weight | 1.9 kg (4.19 lb) |
| Gross Weight | 3.3 kg (7.28 lb) |
| Installation | Installed with bracket |
| Lens | 3.2 mm –10.5 mm |
| Certification | |
| CE, FCC | Yes |
| RoHS | Yes |
